Powered Stretcher > Vivera Clinic

Vivera Clinic

The unique combination of a powered transporter and detachable stretcher provides the possibility of transporting the patient even in less accessible places.

Specification . PDF

Vivera Clinic

The unique combination of a powered transporter and detachable stretcher provides the possibility of transporting the patient even in less accessible places.

Specification . PDF

300 kg

Maximum load capacity

5 Ah

Battery Capacity

Up to 95 cm

Loading height

Vivera Clinic N114-P401

The unique combination of a powered transporter and detachable stretcher provides the possibility of transporting the patient even in less accessible places.

Features

Standard Features

  • Battery-powered hydraulic lift system
  • Integrated battery with battery management system
  • Automatic battery charging in fastener system
  • Manual back-up release handle
  • Battery level indicator
  • Settable load height
  • High visibility powder-coated frame
  • Integrated bumper system
  • One-hand release, fold down siderails
  • One-hand release, infinite positioning, pneumatically assited backrest and legrest
  • Rubber wheels for better shock absorption
  • Steer lock system enables wheels either to swivel or to lock into straight-line position
  • One four-point shoulder restraint and two lap belts
  • Anatomic mattress and pillow
  • Foot-end wheel locks
  • External battery charging using mains power supply

Optional Features

  • Mattress with integrated children restraint
  • Automatic restraints
  • Head extension
  • Siderails extending patient surface
  • One-hand release, infinite positioning headrest (not compatible with head extension)
  • One-hand release, infinite positioning kneerest

Accessories

Vivera Fastener
F401

Detail

Instrument Table
156020

O2 bottle holder
155970

IV pole
2007

Set of static restraints
1724

Anatomic mattress
151690

Extended mattress
146020

Anatomic pillow
1803

Specifications

Transporter Specification

Type P401
Length 200 cm
Width 60 cm
Height of seat section Max 142 cm
Min 47 cm
Weight1 71 kg
Wheels Diameter 15 cm
Width 5 cm
Battery Capacity 5 Ah
Maximum load capacity 300 kg
Loading height < 95 cm
Fastener system2 F401

Stretcher Specification

Type N114
Length 195 cm
Width 56 cm
Height 12 cm
Weight3 20 kg
Maximum load capacity 250 kg
Handle extension 27 cm
Head Extension4 +29 cm
Extended patient surface4 94 cm
Backrest articulation 0° – 90°
Shock frame articulation 0° – 30°
Headrest articulation3 -30°–35°
Kneerest articulation3 0° – 50°

1 Transporter is weighed with battery pack.
2 Meets dynamic crash standards EN-1789 with F401 fastening system.
3 Stretcher is weighed without mattress and restraints.
4 Optional.
Specifications are rounded to the nearest whole number.
MEDIROL reserves the right to change specifications without notice.
